Lindy 300m Cat.6 4 Port VGA Splitter Extender Transmitter by Lindy

Specifications

• AV Interface: VGA
• Interface Standard: -
• Supported Bandwidth: 350MHz
• Maximum Distance: 300m (984.24ft)
• Maximum Resolution: 300m (984.24ft) - 640x480

200m (656.16ft) - 800x600

180m (590.54ft) - 1024x768

120m (393.7ft) - 1280x1024

100m (328.08ft) - 1920x1080

• HDCP Support: -
• EDID Pass Through: -
• Supported Audio: Dual Mono
• Separate Audio Ports: 3.5mm
• IR Support: -
• CEC Support: -
• Serial Interface: -
• Transmission Protocol: -
• Transmission Medium: 1 x Cat.5e/6
• Laser Class (only for Fibre): -
• Wavelength (only for Fibre): -
• Chipset: EL4543IUZ
• Special Features: Local VGA Output with Dual Mono Audio Extraction
• Dual Mono Audio Embedding
• Mountable Housing

Connectors

• Transmitter Input: VGA (Female), 3.5mm (Female)
• Transmitter Output: VGA (Female), 3.5mm (Female), 4 x RJ-45 (Female)
• Receiver Input: -
• Receiver Output: -
• Bi-directional Ports: -
• Power : 5.5/2.1mm

Physical Properties

• Dimensions (approx.) WxDxH: 135.4x73x31mm (5.33x2.87x1.22in)
• Housing Material: Metal
• Net Weight: 0.484kg (1.07lb)
• Operating Temperature : 0°C - 50°C (32°F - 122°F)
• Storage Temperature: -20°C - 70°C (-4°F - 158°F)
• Humidity: 20 - 80% RH (non-condensing)
• Power Requirements: 12VDC 1.2A
• Colour: Black

Miscellaneous

• Packaging Type: Carton Box
• Packaging Dimensions: 177x75x110mm (6.97x2.95x4.33in)
• Gross Weight: 0.547kg (1.21lb)
• Warranty (Years): 2
• Product Compliance: CE, FCC, RoHS, REACH, California Proposition 65, TAA

Package Contents

• 300m 4 Port Cat.6 VGA Splitter
• 4 x Mounting Screws
• Multi-country Power Supply (UK, EU, US & AUS)
• Lindy Manual

Purchasing Information

• No.: 35403
• EAN: 4002888354035
